Page 27 - Materiales avanzados para el sector ferroviario
P. 27

ENTIDAD/ENTITY: TECNALIA
        DEPARTAMENTO/DEPARTMENT: División de Energía y Medioambiente/Energy and
        Environment division
        DIRECCIÓN/ADDRESS: Parque Científico y Tecnológico de Bizkaia, Astondo Bidea,
        Edificio 700, E-48160 Derio, Bizkaia, Spain
        WEBSITE: www.tecnalia.com
        CONTACTO/CONTACT: Fernando Liébana (fernando.liebana@tecnalia.com)

         TRATAMIENTOS TÉRMICOS SUPERFICIALES SELECTIVOS  SELECTIVE SURFACE THERMAL TREATMENTS BASED
         MEDIANTE TECNOLOGÍA LÁSER VCSEL EN                   ON VCSEL TECHNOLOGY APPLIED ON METALLIC

         COMPONENTES METÁLICOS PARA MEJORAR LA                COMPONENTS FOR IMPROVING BOTH IMPACT ENERGY
         CAPACIDAD DE ABSORCIÓN DE ENERGÍA AL IMPACTO  ABSORPTION AND WELDABILITY PROPERTIES
         Y SU SOLDABILIDAD


         DESCRIPCIÓN DE LA TECNOLOGÍA O CONOCIMIENTO          DESCRIPTION OF THE TECHNOLOGY OR KNOWLEDGE
         Diferentes tipologías de tratamientos térmicos       The high power VCSEL (Vertical Cavity Surface
         superficiales pueden ser aplicados con la            Emitting Laser) module is a singular device
         tecnología láser VCSEL (Vertical Cavity Surface      composed by a defined number of emission
         Emiting Laser). Esta tecnología oferece alta         sources individually controllable. Together with the
         repetitividad y gran precisión en el control del     proprietary software DataVCSEL®, enables to
         perfil de temperatura deseado. Sus características   provide spatially and temporally controllable
         principales son las siguientes:                      temperature profiles in the workpiece by one-
            Calentamiento de grandes superficies sin         shoot, offering a pioneer solution for new products
            necesidad de hacer barridos.                      with enhanced customer oriented functionalities. It
            Control muy preciso de la temperatura objetivo  overcomes the limitations of conventional laser
            sin fluctuaciones.                                systems and heat sources regarding spatial
            Alta flexibilidad en la configuración de mapas   flexibility, part size and productivity. The following
            de temperatura mediante el control dinámico e  are its main characteristics:
            independiente de los canales VCSEL.                 Heating of big areas faster than using
                Control espacial de la distribución de          traditional lasers
              temperaturas sobre la superficie.                 Similar wavelength to the traditional diode
                Control temporal de evolución de                lasers.
              temperaturas en cada punto.                       Target Power/Temperature control without
                                                  2
            Densidades de potencia de 100 W/cm  y alta          fluctuations.
            velocidad de procesamiento.                         High flexibility for temperature map
            Equipos compactos y modulares para abarcar          configurations by means of independent
            diferentes superficies.                              dynamic control for each VCSEL channel.
            Menor coste que los sistemas láser                     Spatial control for surface temperature
            convencionales.                                       distribution.
                                                                    Temporal control for the temperature
         TECNALIA ha desarrollado el sistema DataVCSEL®           evolution on each point.
                                                                           2
         que permite:                                           100 W/cm  power density and high speed
            Configuración flexible y monitorización de los      processing.
            equipos VCSEL.                                      Modular and compact equipment for different
            Configuración de las curvas de potencia             geometries processing.
            (Potencia vs tiempo) de cada canal VCSEL.           Less investment costs compared with
            Configuración de las curvas de temperatura          traditional lasers.
            (Temperatura vs tiempo) de cada área de
