R.1. Efficient design of the railway electrical network



                   Investment:                 Nature:                      Improvement:




                   Related to:

                   R.18
                   The areas of work in this field continue to be diverse and focus on the efficient design of
                   electrical infrastructure with an emphasis on good practices and not on the acquisition of
                   specific technology. Among others, these are:

                         Use  of  adequate  reinforcement  sections  to  enable  an  efficient  distribution  of
                          traction current.

                         Project parallel installations between Transmission Lines.

                         Analysis of the reactive energy of the facilities in the project.

                         Adoption of efficient technical teams.

                         Position  of  Neutral  Zones  for  electrical  phase  separation  in  flat  areas  (in  AC
                          systems).

                         Efficient  operation  of  the  railway  Electrical  grid  (R.18),  design  of  a  network
                          topology  that  allows  optimum  use  of  regenerated  energy  based  on  different
                          exploitation scenarios (in DC systems).

                         Use of the highest supply voltages, through receivers connected to the transport
                          network and internal Medium Voltage networks, guaranteeing a better quality of
                          supply, a better electricity price and a greater capacity to take advantage of all the
                          energy regenerated by the recuperators of traction in DC systems.

                   In principle, these areas of work should not be complex for the different users. On the
                   contrary,  it  is  worth  highlighting  two  lines  of  action  that,  as  they  are  specific  to  the
                   corresponding engineering projects, would have a significant impact on the functionality
                   and characteristics of the network. Namely, the increase in the nominal electrical voltage
                   of the Transmission Line and the evolution to single-phase alternating current traction
                   systems instead of direct current (referring to the RFIG). In fact, the latter has already
                   being implemented in recent years, not only in newly built infrastructures, but also in the
                   existing  infrastructures  that  are  electrified.  The  advantages  of  using  this  current  are
                   greater than its main disadvantage (generating disturbances on the external network and
                   on nearby railway facilities).
